Introduction

Python's Global Interpreter Lock (GIL) can make parallel CPU-bound work tricky with threads. Enter multiprocessing: a standard library module that spins up multiple processes to run Python code in parallel, bypassing the GIL. This guide gives you a practical, step-by-step approach to using multiprocessing for efficient data processing, from simple parallel maps to full producer-consumer real-time pipelines.

You'll learn:

• When and why to use multiprocessing.
• How to build common patterns: parallel map, process pools, and queued pipelines.
• Performance tips: chunk sizes, serialization overhead, and shared memory.
• How itertools and async/await can complement multiprocessing.
• Best practices and common pitfalls.

Prerequisites

Before we dive in, ensure you're comfortable with:

• Python 3.x (examples assume 3.8+ for shared_memory features).
• Basic familiarity with functions, iterators, and exceptions.
• Basic terminal usage and installing packages (if needed).

• multiprocessing: https://docs.python.org/3/library/multiprocessing.html
• itertools: https://docs.python.org/3/library/itertools.html
• asyncio: https://docs.python.org/3/library/asyncio.html

Core Concepts

Let's break the topic into core ideas:

• Process vs Thread: Processes run in separate memory spaces and bypass the GIL, making them suitable for CPU-bound tasks. Threads are lighter but still subject to the GIL for CPU-bound code.
• Serialization (Pickle): Data passed between processes is serialized (pickled), which costs time. Large objects can be expensive to send.
• Process startup cost: Creating processes has overhead. Use pools for repeated work.
• Shared memory: Modern Python provides shared_memory and multiprocessing.Value/Array to reduce copying.
• I/O vs CPU-bound: For I/O-bound workloads, asyncio (async/await) or threads often perform better. For CPU-bound work, multiprocessing is usually best.
• Pipelines and Queues: Use multiprocessing.Queue or Manager to build producer-consumer pipelines for streaming data.

How asyncio fits: async/await is excellent for high-concurrency I/O and can be combined with multiprocessing: use async producers/consumers and delegate CPU-heavy tasks to process pools (e.g., with loop.run_in_executor).

Step-by-Step Examples

We'll start with small examples and build up to a real-time pipeline.

Example 1 — Parallel map with multiprocessing.Pool

Use Pool.map for simple parallelism.

# parallel_map_example.py
import multiprocessing as mp
import math
from time import perf_counter
def is_prime(n: int) -> bool:
    if n <= 1:
        return False
    if n <= 3:
        return True
    if n % 2 == 0:
        return False
    r = int(math.sqrt(n))
    for i in range(3, r + 1, 2):
        if n % i == 0:
            return False
    return True
if __name__ == "__main__":
    nums = [106 + i for i in range(2000)]  # CPU-intensive checks
    start = perf_counter()
    with mp.Pool(processes=mp.cpu_count()) as pool:
        results = pool.map(is_prime, nums)
    print("Primes found:", sum(results))
    print("Elapsed:", perf_counter() - start)

# chunking_with_itertools.py
import itertools
from typing import Iterable, List, Any
def chunked(iterable: Iterable, size: int):
    it = iter(iterable)
    while True:
        chunk = list(itertools.islice(it, size))
        if not chunk:
            break
        yield chunk
Usage example
if __name__ == "__main__":
    data = range(1, 101)
    for c in chunked(data, 10):
        print(c)

# pipeline_example.py
import multiprocessing as mp
import time
import random
def producer(out_queue: mp.Queue, n_items: int):
    for i in range(n_items):
        item = {"id": i, "value": random.random()}
        out_queue.put(item)
        time.sleep(0.01)  # simulate I/O or incoming stream
    # Signal consumers to stop
    for _ in range(mp.cpu_count()):
        out_queue.put(None)
def worker(in_queue: mp.Queue, out_queue: mp.Queue):
    while True:
        item = in_queue.get()
        if item is None:  # shutdown signal
            out_queue.put(None)
            break
        # CPU-bound processing simulation
        item["processed"] = item["value"]  2
        out_queue.put(item)
def consumer(in_queue: mp.Queue):
    shutdown_signals = 0
    while True:
        item = in_queue.get()
        if item is None:
            shutdown_signals += 1
            if shutdown_signals >= mp.cpu_count():
                break
            continue
        print("Consumed:", item)
if __name__ == "__main__":
    q1 = mp.Queue(maxsize=100)
    q2 = mp.Queue(maxsize=100)
    p = mp.Process(target=producer, args=(q1, 500))
    p.start()
    workers = []
    for _ in range(mp.cpu_count()):
        w = mp.Process(target=worker, args=(q1, q2))
        w.start()
        workers.append(w)
    consumer_proc = mp.Process(target=consumer, args=(q2,))
    consumer_proc.start()
    p.join()
    for w in workers:
        w.join()
    consumer_proc.join()

Line-by-line:

• producer pushes items to q1 and signals shutdown by sending None per worker.
• worker consumes from q1, processes data, sends results to q2. On None, forwards shutdown to consumer.
• consumer reads q2 and exits after receiving shutdown signals equal to worker count.
• Processes are created and started in __main__ to be safe on Windows.

• maxsize provides a form of backpressure; producers block when q1 fills.
• Use mp.Manager().Queue() if you need a proxy queue for shared state; plain mp.Queue is faster in many cases.

Example 4 — Using concurrent.futures.ProcessPoolExecutor

concurrent.futures provides a higher-level, futures-based API.

# processpool_executor.py
from concurrent.futures import ProcessPoolExecutor, as_completed
import math
def fib(n: int) -> int:
    if n <= 1:
        return n
    a, b = 0, 1
    for _ in range(n-1):
        a, b = b, a + b
    return b
if __name__ == "__main__":
    with ProcessPoolExecutor() as exe:
        futures = [exe.submit(fib, n) for n in range(30, 40)]
        for fut in as_completed(futures):
            print(fut.result())

Explanation:

• ProcessPoolExecutor handles process pool lifecycle.
• submit returns Future objects; use as_completed to process results as they arrive.
• Great for when you need exception handling and timeouts with futures.

Example 5 — Shared memory for large data (numpy arrays)

Large arrays are expensive to copy between processes. Use multiprocessing.shared_memory (Python 3.8+) to share a NumPy array without copying.

# shared_memory_example.py
import numpy as np
from multiprocessing import Process
from multiprocessing import shared_memory
def worker(name, shape, dtype):
    existing_shm = shared_memory.SharedMemory(name=name)
    arr = np.ndarray(shape, dtype=dtype, buffer=existing_shm.buf)
    # modify in place
    arr = 2
    existing_shm.close()

if __name__ == "__main__":
    arr = np.arange(10, dtype=np.int64)
    shm = shared_memory.SharedMemory(create=True, size=arr.nbytes)
    shared_arr = np.ndarray(arr.shape, dtype=arr.dtype, buffer=shm.buf)
    shared_arr[:] = arr[:]  # copy initial data
    p = Process(target=worker, args=(shm.name, arr.shape, arr.dtype))
    p.start()
    p.join()
    print("Modified:", shared_arr)  # should be doubled
    shm.close()
    shm.unlink()

def safe_worker(item):
    try:
        return do_work(item)
    except Exception as e:
        # Log and return a sentinel or re-raise
        return {"error": str(e), "input": item}

# async_with_process_pool.py (concept)
import asyncio
from concurrent.futures import ProcessPoolExecutor
def cpu_task(n):
    # expensive CPU-bound work
    return sum(ii for i in range(n))
async def main():
    loop = asyncio.get_running_loop()
    with ProcessPoolExecutor() as pool:
        tasks = [loop.run_in_executor(pool, cpu_task, 10_000_000) for _ in range(5)]
        results = await asyncio.gather(*tasks)
        print(results)
Run: asyncio.run(main())

Benefits:

• Async handles many concurrent I/O-bound producers.
• CPU tasks are delegated to processes via the executor.
• Ideal for building real-time data pipelines where ingestion is async and processing is CPU-heavy.

Best Practices

• Use if __name__ == "__main__": to guard process creation (required on Windows).
• Prefer ProcessPoolExecutor for simpler code unless you need custom Process behavior.
• Use chunking and tune chunksize.
• Avoid sending big objects repeatedly — use shared memory, files, or databases for large data.
• Handle shutdown gracefully with sentinel values and timeouts.
• Use logging instead of print for production systems and include process IDs in logs.
• Benchmark with realistic workloads and measure end-to-end latency, not just CPU time.

Common Pitfalls

• Forgetting the __main__ guard — causes recursive process spawning on Windows.
• Assuming threads are parallel for CPU-bound work — the GIL prevents true parallel CPU execution.
• Passing unpicklable objects (e.g., open file handles or local functions) to worker processes.
• Not managing process lifecycle (leaking shared memory or orphaned processes).
• Blocking the event loop in asyncio by performing CPU-heavy tasks there instead of offloading them.

Advanced Tips

• Use multiprocessing.shared_memory for large NumPy arrays and use read-only memoryviews where possible.
• For very large data, consider memory-mapped files (numpy.memmap) to avoid transfers.
• Use multiprocessing.SimpleQueue() for faster inter-process messaging in some contexts.
• On Linux, fork can copy-on-write share memory pages; leveraging that can reduce startup copy costs, but be careful with threads and resource handles.
• For cross-machine scalability, use specialized tools (Dask, Ray, Apache Kafka) rather than multiprocessing.

Building Real-Time Data Pipelines: Techniques and Tools

Multiprocessing is one building block for real-time pipelines. Combine it with:

• asyncio for high-throughput I/O ingestion (websockets, HTTP clients).
• itertools for efficient iteration and windowing.
• multiprocessing queues/shared memory for transferring work to CPU processes.
• External systems (Redis, Kafka) for buffering, persistence, and scaling across machines.
• Frameworks like Dask or Ray for distributed processing if you outgrow single-machine multiprocessing.

1. Async producers ingest data concurrently.
2. Items are placed into an in-memory queue or buffer.
3. Worker processes consume, transform, or enrich items.
4. Results are aggregated or forwarded to a sink (DB, filesystem, streaming service).

Conclusion

Multiprocessing is a powerful tool in the Python toolbox for CPU-bound data processing. Use pools to manage worker processes, itertools to simplify iteration and batching, and asyncio when combining high-concurrency I/O with CPU-heavy tasks delegated to processes. Mind serialization costs, use shared memory for large arrays, and always measure performance.

Try the examples:

• Run the Pool and pipeline scripts with realistic data.
• Experiment with chunk sizes, process counts, and shared memory for real gains.
• Combine async producers with process pools for real-time ingestion and CPU-bound processing.

Further Reading

• Official multiprocessing docs: https://docs.python.org/3/library/multiprocessing.html
• itertools docs: https://docs.python.org/3/library/itertools.html
• asyncio docs: https://docs.python.org/3/library/asyncio.html
• multiprocessing.shared_memory (PEP 554 context): https://docs.python.org/3/library/multiprocessing.shared_memory.html
• Dask: https://dask.org
• Ray: https://docs.ray.io
